Name: Hunter Spray Nozzle
SKU: Hunter Spray Head Nozzles
Price: 4.50 NZD
Availability: InStock

Description

Whether dealing with hillside topography, a curved flowerbed, or other special landscape installations, challenging angles demand nozzles that adjust to their surroundings. Hunter Pro Adjustable Nozzles cover any angle needed on any landscape with the accuracy of a fixed nozzle. Engineered to emit larger than average water droplets, these nozzles are reliable, accurate, and fully adjustable to any angle from 0° to 360°. Pro Adjustable Nozzles are available in seven models that cover distances from 1.2 m to 5.2 m using recommended pressure. For easy inventory and field ID, models are colour-coded based on throw distance.

FEATURES

Crisp, well-defined edges
Matched precipitation rate on each nozzle from 8A to 17A
Easy-grip top for simple adjustment
Large water droplets cut through wind
Even distribution results in better coverage
1.2 m and 1.8 m radius options provide additional flexibility
Colour-coded for easy field identification
Adjustable from 0° to 360°
Operating Specifications
- Recommended operating pressure: 2.1 bar; 210 kPa
- Specify the new Pro-Spray® PRS30 pop-up for accurate pressure regulation of 2.1 bar; 210 kPa

FEATURES

Crisp, well-defined edges
Matched precipitation rate on each nozzle from 8A to 17A
Easy-grip top for simple adjustment
Large water droplets cut through wind
Even distribution results in better coverage
1.2 m and 1.8 m radius options provide additional flexibility
Colour-coded for easy field identification
Adjustable from 0° to 360°

Radius: 1.2 m

Radius: 1.8 m

Radius: 2.4 m

10A

Radius: 3.0 m

12A

Radius: 3.7 m

15A

Radius: 4.6 m

17A

Radius: 5.2 m

NOZZLE COMPARISON CHART

A Nozzle for Every Occasion
From the water-saving MP Rotator, to standard sprays and side-stripped specialty nozzles, Hunter provides a solution you can trust for years on end.


	MP ROTATOR	MP ROTATOR MP800 SERIES	PRECISION DISTRIBUTION CONTROL™ NOZZLES	PRO-SPRAY FIXED ARC NOZZLES	SIDE STRIP	SHORT RADIUS	BUBBLERS
QUICK SPECS
NOZZLE TYPES	HIGH EFFICIENCY ROTATOR NOZZLE	SHORT RADIUS HIGH EFFICIENCY ROTATOR NOZZLE	ADJUSTABLE SPRAY	FIXED SPRAY	SIDE STRIP	SPECIALTY NOZZLE	SPECIALTY NOZZLE
RADIUS	2.5–10.7 m	1.8–4.9 m	1.2–5.2 m	1.5–5.2 m	2.7 x 5.5 / 2.4 x 8.5 / 1.5 x 9.0 / 1.5 x 4.5 m	0.6, 1.2, 1.8 m	0.30–0.46 m
WARRANTY	3 Years	3 Years	2 Years	2 Years	2 Years	2 Years	2 Years
FEATURES
ARC	45–360	90–360	0–360	90–360	Rectangle	90 or 180	90–360
PRECIPITATION SQUARE	Approx. 10 mm/hr	Approx. 20 mm/hr	40–133 mm/hr	41–49 mm/hr	N/A	139–222 mm/hr	N/A
PRECIPITATION TRIANGLE	Approx. 11 mm/hr	Approx. 22 mm/hr	46–154 mm/hr	47–57 mm/hr	N/A	160–257 mm/hr	N/A
ADVANCED FEATURES
COLOR CODED
AUTOMATIC MATCHED PRECIPITATION
MAXIMUM WATER EFFICIENCY
PRESSURE COMPENSATING
APPLICATIONS
STRIP PATTERN
STREAM SPRAY
SHORT RADIUS
DEEP WATERING

Operating Specifications

Recommended operating pressure: 2.1 bar; 210 kPa
Specify the new Pro-Spray® PRS30 pop-up for accurate pressure regulation of 2.1 bar; 210 kPa

PRO ADJUSTABLE NOZZLE PERFORMANCE DATA

4A & 6A

			NOZZLE 4A LT. GREEN • 1.2 m radius Adjustable from 0° to 360 Trajectory 0°					NOZZLE 6A LT. BLUE • 1.8 m radius Adjustable from 0° to 360 Trajectory 0°
Arc	Pressure		Radius	Flow		Precip mm/hr		Radius	Flow		Precip mm/hr
	bar	kPa	m	m³/hr	l/min			m	m³/hr	l/min
45°	1.0	100	0.9	0.02	0.31	187	216	1.5	0.03	0.54	117	136
	1.5	150	1.0	0.02	0.39	178	206	1.6	0.04	0.60	108	124
	2.1	210	1.2	0.03	0.48	167	193	1.8	0.04	0.65	98	114
	2.5	250	1.3	0.03	0.56	158	183	1.9	0.04	0.70	92	106
	3.0	300	1.4	0.04	0.64	149	172	2.1	0.05	0.75	86	99
90°	1.0	100	0.9	0.04	0.72	213	246	1.5	0.06	1.08	116	134
	1.5	150	1.0	0.05	0.76	182	210	1.6	0.07	1.21	109	126
	2.1	210	1.2	0.05	0.83	139	160	1.8	0.08	1.35	102	118
	2.5	250	1.3	0.05	0.91	129	149	1.9	0.09	1.47	97	112
	3.0	300	1.4	0.06	0.95	116	134	2.1	0.10	1.61	92	106
120°	1.0	100	0.9	0.06	0.97	221	255	1.5	0.08	1.26	102	118
	1.5	150	1.0	0.07	1.10	188	217	1.6	0.09	1.43	97	112
	2.1	210	1.2	0.07	1.25	162	187	1.8	0.10	1.61	91	105
	2.5	250	1.3	0.08	1.36	146	168	1.9	0.11	1.76	87	100
	3.0	300	1.4	0.09	1.49	131	151	2.1	0.12	1.93	82	95
180°	1.0	100	0.9	0.07	1.18	178	206	1.5	0.10	1.70	92	106
	1.5	150	1.0	0.08	1.38	157	181	1.6	0.12	1.96	88	102
	2.1	210	1.2	0.10	1.60	139	160	1.8	0.13	2.24	84	97
	2.5	250	1.3	0.11	1.78	127	146	1.9	0.15	2.47	81	94
	3.0	300	1.4	0.12	1.98	115	133	2.1	0.16	2.72	78	90
240°	1.0	100	0.9	0.12	1.94	220	254	1.5	0.15	2.44	99	114
	1.5	150	1.0	0.13	2.24	192	221	1.6	0.17	2.83	96	111
	2.1	210	1.2	0.16	2.59	168	194	1.8	0.20	3.28	92	107
	2.5	250	1.3	0.17	2.86	153	177	1.9	0.22	3.63	89	103
	3.0	300	1.4	0.19	3.17	139	160	2.1	0.24	4.03	86	99
270°	1.0	100	0.9	0.13	2.09	211	244	1.5	0.18	3.08	111	128
	1.5	150	1.0	0.14	2.40	183	211	1.6	0.21	3.52	106	122
	2.1	210	1.2	0.16	2.75	159	183	1.8	0.24	4.02	101	116
	2.5	250	1.3	0.18	3.02	144	166	1.9	0.27	4.42	97	112
	3.0	300	1.4	0.20	3.33	130	150	2.1	0.29	4.87	92	107
360°	1.0	100	0.9	0.14	2.26	171	197	1.5	0.21	3.57	96	111
	1.5	150	1.0	0.16	2.60	148	171	1.6	0.24	4.07	92	106
	2.1	210	1.2	0.18	2.98	129	149	1.8	0.28	4.62	87	100
	2.5	250	1.3	0.20	3.29	117	135	1.9	0.30	5.06	83	96
	3.0	300	1.4	0.22	3.63	106	122	2.1	0.33	5.56	79	92

8A & 10A

			NOZZLE 8A BROWN • 2.4 m radius Adjustable from 0° to 360 Trajectory 0°					NOZZLE 10A RED • 3.0 m radius Adjustable from 0° to 360 Trajectory 15°
Arc	Pressure		Radius	Flow		Precip mm/hr		Radius	Flow		Precip mm/hr
	bar	kPa	m	m³/hr	l/min			m	m³/hr	l/min
45°	1.0	100	2.0	0.04	0.62	77	89	2.6	0.04	0.68	49	56
	1.5	150	2.2	0.04	0.72	72	83	2.8	0.05	0.80	49	57
	2.1	210	2.4	0.05	0.83	67	77	3.0	0.06	0.94	49	56
	2.5	250	2.6	0.05	0.91	63	73	3.2	0.06	1.06	48	56
	3.0	300	2.9	0.06	1.01	59	68	3.5	0.07	1.18	47	54
90°	1.0	100	2.0	0.07	1.24	77	89	2.6	0.08	1.35	49	56
	1.5	150	2.2	0.09	1.44	72	83	2.8	0.10	1.61	49	57
	2.1	210	2.4	0.10	1.65	67	77	3.0	0.11	1.89	49	56
	2.5	250	2.6	0.11	1.82	63	73	3.2	0.13	2.11	48	56
	3.0	300	2.9	0.12	2.02	59	68	3.5	0.14	2.37	47	54
120°	1.0	100	2.0	0.10	1.66	77	89	2.6	0.11	1.80	49	56
	1.5	150	2.2	0.11	1.92	72	83	2.8	0.13	2.14	49	57
	2.1	210	2.4	0.13	2.20	67	77	3.0	0.15	2.52	49	56
	2.5	250	2.6	0.15	2.43	63	73	3.2	0.17	2.82	48	56
	3.0	300	2.9	0.16	2.69	59	68	3.5	0.19	3.16	47	54
180°	1.0	100	2.0	0.15	2.49	77	89	2.6	0.16	2.71	49	56
	1.5	150	2.2	0.17	2.87	72	83	2.8	0.19	3.21	49	57
	2.1	210	2.4	0.20	3.30	67	77	3.0	0.23	3.78	49	56
	2.5	250	2.6	0.22	3.65	63	73	3.2	0.25	4.23	48	56
	3.0	300	2.9	0.24	4.03	59	68	3.5	0.28	4.73	47	54
240°	1.0	100	2.0	0.20	3.32	77	89	2.6	0.22	3.61	49	56
	1.5	150	2.2	0.23	3.83	72	83	2.8	0.26	4.28	49	57
	2.1	210	2.4	0.26	4.40	67	77	3.0	0.30	5.03	49	56
	2.5	250	2.6	0.29	4.86	63	73	3.2	0.34	5.64	48	56
	3.0	300	2.9	0.32	5.38	59	68	3.5	0.38	6.31	47	54
270°	1.0	100	2.0	0.22	3.73	77	89	2.6	0.24	4.06	49	56
	1.5	150	2.2	0.26	4.31	72	83	2.8	0.29	4.82	49	57
	2.1	210	2.4	0.30	4.95	67	77	3.0	0.34	5.66	49	56
	2.5	250	2.6	0.33	5.47	63	73	3.2	0.38	6.34	48	56
	3.0	300	2.9	0.36	6.05	59	68	3.5	0.43	7.10	47	54
360°	1.0	100	2.0	0.30	4.97	77	89	2.6	0.32	5.41	49	56
	1.5	150	2.2	0.34	5.75	72	83	2.8	0.39	6.43	49	57
	2.1	210	2.4	0.40	6.61	67	77	3.0	0.45	7.55	49	56
	2.5	250	2.6	0.44	7.29	63	73	3.2	0.51	8.45	48	56
	3.0	300	2.9	0.48	8.07	59	68	3.5	0.57	9.47	47	54

12A, 15A & 17A

			NOZZLE 12A GREEN • 3.7 m radius Adjustable from 0° to 360 Trajectory 28°					NOZZLE 15A BLACK • 4.6 m radius Adjustable from 0° to 360 Trajectory 28°					NOZZLE 17A GREY • 5.2 m radius Adjustable from 0° to 360 Trajectory 28°
Arc	Pressure		Radius	Flow		Precip mm/hr		Radius	Flow		Precip mm/hr		Radius	Flow		Precip mm/hr
	bar	kPa	m	m³/hr	l/min			m	m³/hr	l/min			m	m³/hr	l/min
45°	1.0	100	3.2	0.04	0.73	34	40	4.0	0.08	1.27	38	43	4.6	0.10	1.68	38	43
	1.5	150	3.4	0.06	0.97	40	46	4.3	0.09	1.51	39	45	4.9	0.12	1.94	38	44
	2.1	210	3.7	0.07	1.23	44	51	4.6	0.11	1.79	40	46	5.2	0.13	2.23	39	45
	2.5	250	3.9	0.09	1.44	46	54	4.9	0.12	2.00	40	46	5.5	0.15	2.46	39	45
	3.0	300	4.1	0.10	1.68	48	56	5.2	0.14	2.25	40	46	5.8	0.16	2.72	39	45
90°	1.0	100	3.2	0.09	1.46	34	40	4.0	0.15	2.53	38	43	4.6	0.20	3.36	38	43
	1.5	150	3.4	0.12	1.93	40	46	4.3	0.18	3.03	39	45	4.9	0.23	3.88	38	44
	2.1	210	3.7	0.15	2.46	44	51	4.6	0.21	3.57	40	46	5.2	0.27	4.45	39	45
	2.5	250	3.9	0.17	2.88	46	54	4.9	0.24	4.01	40	46	5.5	0.30	4.92	39	45
	3.0	300	4.1	0.20	3.36	48	56	5.2	0.27	4.50	40	46	5.8	0.33	5.44	39	45
120°	1.0	100	3.2	0.12	1.94	34	40	4.0	0.20	3.38	38	43	4.6	0.27	4.48	38	43
	1.5	150	3.4	0.15	2.58	40	46	4.3	0.24	4.03	39	45	4.9	0.31	5.17	38	44
	2.1	210	3.7	0.20	3.28	44	51	4.6	0.29	4.76	40	46	5.2	0.36	5.94	39	45
	2.5	250	3.9	0.23	3.84	46	54	4.9	0.32	5.34	40	46	5.5	0.39	6.56	39	45
	3.0	300	4.1	0.27	4.48	48	56	5.2	0.36	6.00	40	46	5.8	0.43	7.25	39	45
180°	1.0	100	3.2	0.17	2.91	34	40	4.0	0.30	5.07	38	43	4.6	0.40	6.71	38	43
	1.5	150	3.4	0.23	3.86	40	46	4.3	0.36	6.05	39	45	4.9	0.47	7.75	38	44
	2.1	210	3.7	0.30	4.92	44	51	4.6	0.43	7.14	40	46	5.2	0.53	8.91	39	45
	2.5	250	3.9	0.35	5.76	46	54	4.9	0.48	8.02	40	46	5.5	0.59	9.83	39	45
	3.0	300	4.1	0.40	6.71	48	56	5.2	0.54	9.00	40	46	5.8	0.65	10.87	39	45
240°	1.0	100	3.2	0.23	3.88	34	40	4.0	0.41	6.76	38	43	4.6	0.54	8.95	38	43
	1.5	150	3.4	0.31	5.15	40	46	4.3	0.48	8.07	39	45	4.9	0.62	10.34	38	44
	2.1	210	3.7	0.39	6.56	44	51	4.6	0.57	9.52	40	46	5.2	0.71	11.88	39	45
	2.5	250	3.9	0.46	7.68	46	54	4.9	0.64	10.69	40	46	5.5	0.79	13.11	39	45
	3.0	300	4.1	0.54	8.95	48	56	5.2	0.72	12.00	40	46	5.8	0.87	14.50	39	45
270°	1.0	100	3.2	0.26	4.37	34	40	4.0	0.46	7.60	38	43	4.6	0.60	10.07	38	43
	1.5	150	3.4	0.35	5.80	40	46	4.3	0.54	9.08	39	45	4.9	0.70	11.63	38	44
	2.1	210	3.7	0.44	7.38	44	51	4.6	0.64	10.71	40	46	5.2	0.80	13.36	39	45
	2.5	250	3.9	0.52	8.65	46	54	4.9	0.72	12.03	40	46	5.5	0.89	14.75	39	45
	3.0	300	4.1	0.60	10.07	48	56	5.2	0.81	13.50	40	46	5.8	0.98	16.31	39	45
360°	1.0	100	3.2	0.35	5.83	34	40	4.0	0.61	10.13	38	43	4.6	0.81	13.43	38	43
	1.5	150	3.4	0.46	7.73	40	46	4.3	0.73	12.10	39	45	4.9	0.93	15.51	38	44
	2.1	210	3.7	0.59	9.84	44	51	4.6	0.86	14.28	40	46	5.2	1.07	17.82	39	45
	2.5	250	3.9	0.69	11.53	46	54	4.9	0.96	16.03	40	46	5.5	1.18	19.67	39	45
	3.0	300	4.1	0.81	13.43	48	56	5.2	1.08	18.00	40	46	5.8	1.30	21.75	39	45

Bold = Recommended pressure

Note: The Pro-Spray PRS30’s built-in pressure regulator controls output to a maximum of 2.1 bar; 210 kPa. Adjusting the radius reduction screw may be required to achieve catalogue radius and flow.

Additional information

Weight	1 kg
Hunter Spray Head Nozzles	HSN4A, HSN6A, HSN8A, HSN10A, HSN12A, HSN15A, HSN17A
